Getting Started
© Radiodetection 2016 13 RD1500 Operation Manual
Section 5 - Getting Started
5.1 Powering up
1. When the battery is first plugged in, the LED goes green for 5 seconds then disappears.
2. To start the system, press the red power button on the display unit. The LED on the front
panel will light up red.
Figure 5-1: Front of Display Unit
Once boot up is complete, the color of the LED will indicate the amount of battery power
remaining:
 100% to 20% = green
 20% to 10% = orange
 10% to 0% = red
Once the system boots up, you will see the main screen (Figure 5-2). If you have purchased
(or upgraded to) the RD1500 Enhanced system, you will see the main screen shown in
Figure 5-3.
LED
Power
button
