Assembly
RD1500 Operation Manual 10 © Radiodetection 2016
4.2 External GPS (optional)
The instructions for connecting the GPS, mount and cable are below:
GPS Mount The GPS mount attaches to the crossbar frame above the battery, using a quick
release pin. Please remove the pipe plug first.
With the pole pointing upwards, insert the GPS mount into the opening where the plug was
located, and secure it with the quick release pin. This allows the GPS to sit directly over the
middle of the GPR sensor. It comes with 5/8-11 UNC-1A threads at the top of the pole, which is
standard for many GPS receivers.
