© Radiodetection 2016 27 RD1500 Operation Manual
survey path travelled, as well as any flags or interpretations (“interps”) added to the data. Map
View is fully explained in Section 11. While Map View is available in both configurations, the
Map View button in File Management is only available in the Enhanced version.
Figure 6-8: Map View showing two grids and a long line with interpretations. Map View is
enabled because the data was collected with GPS.
Export Data
Screenshots and data are always saved to the internal memory of the Display Unit. If a USB-
drive (memory stick) is inserted into the USB port on the Display Unit, pressing the Export Data
button will copy all the data files to the USB-drive. If no USB-drive is inserted, this option will not
be accessible.
6.4 System Test
The System Test sub-menu (Figure 6-9) allows the user to perform certain tests to ensure
proper operation of the system. Select the component to test then press Start. After completing
a test there is an indication of whether the system passed or failed the test. Each test is
described below in more detail.
