Radiodetection RD1500 User Manual

Warranty
73
Section 16 - Technical Specifications
Specifications
Values
GPR Sensor size
630 x 410 x 230 mm (25 x 16 x 9 in)
GPR Sensor weight
5 kg (11 lbs)
Display Unit weight
2.83 kg (6.24 lbs)
Display Unit screen
8.0" diagonal, high-visibility, sunlight-readable LCD display with
touch screen
Adjustable backlighting
1500 NIT and 800:1 contrast ratio
Wireless
Integrated modules:
Wi-Fi (IEEE 802.11 b,g,n)
GPS/GLONASS
Audio
Built-in speaker - 85dBA speaker with volume control
Battery
Lead acid gel cell
Battery Life: 4-6 hours
Battery Capacity:9.0 Ah
Battery weight
4 kg (8.8 lbs)
Battery charger
Built-in charger with status indicator
Universal AC mains charger input: 100-240V , 1.5A,
50/60Hz
Output: 12 Volts @ 3 Amps
DVL-500N Display Unit
Input
11-18V , 4A maximum
Temperature &
Environmental
Ruggedized, environmentally sealed unit and connections.
Ingress protection (IP) rating: DVL-500N Display Unit is rated
to IP65 under IEC 60529
Relative Humidity operation (non-condensing): 10 – 90%
GPR Sensor and DVL-500N operating temperature range: -40
to 50°C (-40 to 122°F)
Do not use touch screen below -20°C (-4°F)
Use battery charger between 0 and 30°C (32° to 85°F).
Regulatory
Specifications
EMC-FCC, CE, IC, ACA, RSM
Safety-TUV, CE
