Line Scan
© Radiodetection 2016 49 RD1500 Operation Manual
Pause button (only available in No Save Mode)
The Pause button allows you to stop data collection temporarily, and then resume again, without
clearing the data from the screen. This might be useful if you want to collect a series of parallel
lines over a target and show all the passes on the screen for comparison.
Once you collect some data, press Pause. You can now move the LMX200 without data
scrolling on the screen. When you are ready to resume collecting data, press Start. You will see
a thick, red vertical line, corresponding to when you hit the Pause button and then restarted
(Figure 8-17).
Figure 8-17: Pressing Pause and resuming data collection.
Drawing arrows (only available in No Save Mode)
There is no option for Interps in this mode, as the data is not being saved. However, you do
have the ability to draw arrows on the screen (Figure 8-18).
