RadioLink AT10 User Manual

42
GOAL of EXAMPLE: STEPS: INPUTS:
Activate twin aileron servos using
AIL-
DIFF
.
Note that the function defaults to no
difference in down travel vs. up travel.
If you want differential travel, simply
adjust each side. (Ex: 90%)
Open the
AIL-DIFF
function.
for 1 second.
(If
BASIC
, again.)
C
to
AIL-DIFF
. *
Activate the function.
C
to
MIX
. to
ACT
.
2SWLRQDODGMXVWWKHXSGRZQWUDYHO
separately for the 2 servos.
(Ex: adjust to
90%
.)
C
to
AIL1
. AILERON STICK.
to
90%
.
C
to
AIL2
. AILERON STICK.
to
90%
.
Close menu.
Where next? Adjust individual servo's
SUB-TRIMs
: see p. 36 and
END POINTs
: see p. 27.
Set up
AIRBRAKE
mix: see p. 48.
Set up
ELEV-FLAP
PL[RQO\LIPRGHOKDVDÀDSVHUYRLQ&+VHHS
Set up
SNAP-ROLL
Function: see p. 45.
View additional model setups: www.radiolink.com.cn/doce/
*If you receive an error message that
OTHER WING MIXING IS ON
, you must deactivate
ELEVON
or
FLAPERON
. See p. 43.
Using Twin Aileron Servos with a 5-channel receiver,
AILE-2
(
ACRO

GLID
):
AILE-2
allows
FLAPERON
and
AIL-DIFF
with a 5-channel receiver.
AILE-2
only tells
the radio that you are using CH5 and CH6 (
FLAPERON
), or CH5 and CH7 (
AIL-
DIFF
), not CH6 or CH7, as the second servo in
FLAPERON
or
AILE-DIFF
. You still
must activate and set up the
FLAPERON

AILE-DIFF
function.
Note that selecting
CH6&5
or
CH7&5
does NOT free up CH6 or CH7 to be used for other functions when using a receiver
with more than 5 channels. Both 5 and 6 (
FLAPERON

AILE-DIFF
) are dedicated to the
FLAPERON
or
AILE-DIFF
programming.
>7KLVLVEHQH¿FLDOZLWKIRXUDLOHURQVHUYRVWKDWQHHGWRKDYHWKHLUHQGSRLQWVRUVXEWULPVVHWVHSDUDWHO\&+&+DQG
CH6 are already fully set up to operate as ailerons. Mix CH7 or CH8 (the second aileron servo on the other side) into
ailerons to function properly.]
Aircraft tail types (
ACRO

GLID
):
GOAL of EXAMPLE: STEPS: INPUTS:
Adjust the second aileron servo output
from
CH6or7
to channels
CH6&5
.
Allows twin aileron servo operation
with a 5-channel receiver.
Open the
PARAMETER
submenu.
for 1 second.
(If
ADVANCE
, again.)
C
to
PARAMETER
.
Select
AILE-2
and change to
CH6&5
.
C
to
AILE-2
. to
CH6&5
.
Close menu.
Where next? Finish setting up
FLAPERON
or
AILE-DIFF
. see Twin Aileron Servos: p. 39.
View additional model setups on the internet: www.radiolink.com.cn/doce
48.

RadioLink AT10 Specifications

General

Channels	10
Frequency	2.4GHz
Output Signal	PPM
Control Distance	1.5km
Compatibility	Compatible with most multi-rotor, airplane, helicopter and car models
