Rain Bird ESP-Me User Manual

6
6
Basic Operation
ESP-Me Advanced User Manual
Basic Operation
Set Date
Set the current calendar Date.
1. Turn the dial to Set Date.
2. Press or to set the DAY,
then press .
3. Press or to set the MONTH,
then press .
4. Press or to set the YEAR.
04JAN12
DAY MONTH YEAR
Set Time
Set the current Time of day.
1. Turn the dial to Set Time.
2. Press or to set the HOUR
(ensure that the AM/PM setting is
correct), then press .
3. Press or to set the MINUTES.
AM
1200
MINUTESHOUR

NOTE: The time will switch from AM to PM
automatically. (Press and HOLD or to
accelerate adjustments).
To change the time format (12 hour or 24 hour):
4. With MINUTES blinking, press .
1200
MINUTESHOUR
AM
5. Press or to select the desired time format,
then press to return to the time setting.
12-HR

NOTE: The time format will default to your region
based upon the electrical current that the controller
detects. You can modify by following the steps
above.
A B C D
Program Select
Select a program to create or modify
irrigation schedules.
1. Press the Program Select button to select the desired
program, A, B, C or D.
PROGRAM
SELECT
A B C D
PGM
A
MINUT ESHOUR
RUN TIME
120

NOTE: Make sure the desired program (A, B, C or D)
is shown on the display during programming.

Rain Bird ESP-Me Specifications

General

Type	Modular
Start Times per Program	4
Master Valve/Pump Start	Yes
Watering Start Times	4 per program
Cycle and Soak	Yes
Rain Delay	Yes
Power Source	24V AC
Voltage	24V AC
Station Run Times	1 minute to 4 hours
Backup Battery	No
