Introduction
4
ESP-Me Advanced User Manual
Display Legend
This manual uses USA domestic icons for illustration purposes. The following table lists the dierences between the domestic
and international display screen symbols. Choose your voltage below to determine the LCD symbols for your controller.
Domestic vs. International Display Symbols
120V & 240V 230V English
OFF O
NEXT
Next Watering Day
MO 1 Monday
TU 2 Tuesday
WE 3 Wednesday
TH 4 Thursday
FR 5 Friday
SA 6 Saturday
SU 7 Sunday
DAY DD Day
MONTH MM Month
YEAR YY Year
HOUR HH Hour
MINUTE MM Minute
1 3 5, , ...
ODD
1 3 5, , ...29
1, 3, 5
Odd Days
2 4 6, , ...
EVEN
2 4 6 30, , ...
2, 4, 6
Even Days
STATION Station
START TIME Start Time
RUN TIME Run Time
REMAINING RUN TIME Remaining Run Time
SEASONAL ADJUST % Seasonal Adjust
DELAY Rain Delay
MANUAL Manual Watering
TEST Test All Stations
DELAY
DELAY
Delay Between Valves

Rain Bird ESP-Me Specifications

General

Type	Modular
Start Times per Program	4
Master Valve/Pump Start	Yes
Watering Start Times	4 per program
Cycle and Soak	Yes
Rain Delay	Yes
Power Source	24V AC
Voltage	24V AC
Station Run Times	1 minute to 4 hours
Backup Battery	No
