ISCOM5508 (B) Hardware Description
2 Components
Raisecom Technology Co., Ltd.
5
Component
Name
Description
RPD1101-48S12
-48 VDC power module
Fan module
FANS306
Fan module
2.1.2 Appearances of components
Appearance of MCC
Figure 2-1 shows the appearance of the MCC (EPSC).
Figure 2-1 Appearance of the MCC (EPSC)
Appearance of sub-card
Figure 2-2 shows the appearance of the EP4B sub-card.
Figure 2-2 Appearance of the EP4B sub-card
Figure 2-3 shows the appearance of the GE4B sub-card.
