4 Pluggable modules
Raisecom Technology Co., Ltd.
34
4 Pluggable modules
This chapter describes pluggable modules of the ISCOM5508, including the following
sections:

1000 Mbit/s SFP optical module

1000 Mbit/s SFP electrical module

PON SFP optical module
4.1 1000 Mbit/s SFP optical module
4.1.1 Functions and appearance
The 1000 Mbit/s Small Form-factor Pluggables (SFP) optical module is applicable to the
1000 Mbit/s telecommunication network. It is integrated with sending and receiving features.
Figure 4-1 shows the appearance of the 1000 Mbit/s SFP optical module.
Figure 4-1 1000 Mbit/s SFP optical module
4.1.2 Label
There is a label on the bottom of the SFP optical module, which describes the model of the
SFP optical module, as shown in Figure 4-2.
