5 Lookup table of LEDs
Table 5-1 lists LEDs of the ISCOM5508.
Table 5-1 LEDs of the ISCOM5508
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is working properly.

Off: the power supply is working improperly.
SYS
Green
System working LED

Blinking green: the system is working properly.

Off: the system is working improperly or the card is
inserted improperly.
LNK/ACT
1/2/3/4
(SFP optical
interface)
Green
Line working LED

Green: the interface is connected properly.

Blinking green: the interface is transmitting data.

Off: the interface is disconnected or connected
improperly.
LNK/ACT 1/2
(RJ45 electrical
interface
integrated LED)
Green
Line working LED

Green: the interface is connected properly.

Blinking green: the interface is transmitting data.

Off: the interface is disconnected or connected
improperly.
1000M
(RJ45 electrical
interface
integrated LED)
Yellow
Electrical interface working rate LED

Yellow: the electrical interface is working at 1000 Mbit/s.

Off: the electrical interface is working at 100 Mbit/s or the
interface fails.
LNK 1/2/3/4
Green
PON interface working LED

Green: the PON interface is connected properly and there
is a registered ONU working on the interface or there is a
long-luminous ONU.

Off: the PON interface is disconnected or there is no
registered ONU working on the interface.
