ISCOM5508 (B) Hardware Description
3 Fiber and cables
Raisecom Technology Co., Ltd.
33
Table 3-13 Technical specifications of the OT terminal
Item
Description
Model
Protective grounding round pressed terminal (M4)
Standard
JB2436-78
Specifications

4.3 soldering lug

Inner radius of soldering lug: 4 mm

Outer radius of soldering lug: ≤ 8 mm

Inner radius of sheath: 2.1 mm

Thickness of soldering lug: ≥ 0.6 mm
Cross-sectional area
of conducting wire
16–15 AWG (1.2–1.5 mm
2
)

The ISCOM5508 is delivered without the grounding cable. If required, prepare or
make grounding cables on site.

The grounding cable cannot be longer than 30 m and should be as short as
possible; otherwise, a grounding bar should be used.
