Raisecom
ISCOM5508 (B) Hardware Description
2 Components
Raisecom Technology Co., Ltd.
16
Table 2-17 LEDs on the RPA1101 power module
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is working properly.

Off: the power supply is working improperly.
AC
Green
Power input LED

Green: the input power is working properly.

Off: the device is powered off or powered on improperly.
ALM
Red
Alarm LED

Red: the device is powered on improperly.

Off: the device is powered off or powered on properly.
2.5.5 Technical specifications
Table 2-18 lists technical specifications of the RPA1101 power module.
Table 2-18 Technical specifications of the RPA1101 power module
Item
Description
Dimensions
65.6 mm (Width) × 240.6 mm (Depth) × 41.2 mm (Height)
Weight
0.61 kg
AC
power
Rated voltage
110/220 VAC
Frequency
50/60 Hz
Voltage range
100–240 VAC
Output power
100 W
Lightning protection level
(AC power)

Differential mode:1 kV

Common mode: 2 kV
2.6 DC power module (RPD1101-48S12)
2.6.1 Introduction
The RPD1101-48S12 (hereinafter referred to as RPD1101) module is the DC power module
of the ISCOM5508. It supports the following features:

Wide voltage input: -38 to -72 VDC

Rated output voltage: 12 V; rated output current: 8.3 A

Output overvoltage and overcurrent protection and reverse connection protection

Power status LED

Operating temperature: -10 to +70°C
