ISCOM5508 (B) Hardware Description
2 Components
Raisecom Technology Co., Ltd.
18
LED
Status
Description
ALM
Red
Alarm LED

Red: the device is powered on improperly.

Off: the device is powered off or powered on properly.
2.6.5 Technical specifications
Table 2-21 lists technical specifications of the RPD1101 power module.
Table 2-21 Technical specifications of the RPD1101 power module
Item
Description
Dimensions
65.6 mm (Width) × 240.6 mm (Depth) × 41.2 mm (Height)
Weight
0.49 kg
DC power
Rated voltage
-48 VDC
Voltage range
-38 to -72 VDC
Output power
100 W
2.7 Fan module (FANS306)
2.7.1 Introduction
The FANS306 module is the fan module of the ISCOM5508. It supports the following
features:

Support fan monitoring. The system monitors the working status of the fan and an alarm
is generated when the fan fails.

Support adjusting the rotational speed of the fan manually or automatically.

Support hot swapping.
2.7.2 Panel and slots
The FANS306 module can be inserted into slot 6 of the ISCOM5508.
Figure 2-12 shows the panel of the FANS306 module.
