ISCOM5508 (B) Hardware Description
3 Fiber and cables
Raisecom Technology Co., Ltd.
30
3.5.2 Appearance
The AC power cable which meets European standard is composed of a European standard
French mode 3-pin plug and a receptacle, as shown in Figure 3-10.
Figure 3-10 European standard AC power cable
The AC power cable which meets American standard is composed of an American standard 3-
pin plug and a receptacle, as shown in Figure 3-11.
Figure 3-11 American standard AC power cable
3.5.3 Technical specifications
Table 3-10 lists technical specifications of the European standard AC power cable.
Table 3-10 Technical specifications of the European standard AC power cable
Item
Description
Name
European standard French mode head/receptacle-10A/250V-D/RoHS
Connector
European standard French mode 3-pin plug and IEC60320-C13 receptacle
Model
Copper core multi-strand power cable 18 AWG (0.75 mm
2
)
Length
The letter D indicates the length, which is customized. For example, if the
customer requires 2-meter cables, they are named European standard
French mode head-receptacle-10A/250V-2m/RoHS.
Table 3-11 lists technical specifications of the American standard AC power cable.
Table 3-11 Technical specifications of the American standard AC power cable
Item
Description
Name
American standard-3 pin-10A/250V-D/RoHS
Connector
American standard 3-pin plug NEMA5-15 and IEC60320-C13 receptacle
Model
Copper core multi-strand power cable 18 AWG (0.75 mm
2
)
