ISCOM5508 (B) Hardware Description
2 Components
Raisecom Technology Co., Ltd.
7
2.1.3 Hardware information label
Hardware information of ISCOM5508 components will be described by a label pasted on the
Printed Circuit Board (PCB) to facilitate you to view it, as shown in Figure 2-6.
Figure 2-6 Hardware information label on the ISCOM5508
The position of hardware information labels may be different because the layouts of
elements are different, so search for it carefully.
Table 2-2 lists items on the hardware information label.
Table 2-2 Items on the hardware information label
Item
Description
P/N
Name and type of the component
REV
Hardware version of the component, where "A" means a release
version and "00" means a build
Bar code
Bar code of the component
