ISCOM5508 (B) Hardware Description
2 Components
Raisecom Technology Co., Ltd.
14
Table 2-14 LEDs on the GE4B sub-card
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is working properly.

Off: the power supply is working improperly.
SYS
Green
System working LED

Fast blinking green (4 Hz): the system is initializing.

Slow blinking green (0.5 Hz): the system is working properly.

Off: the system is working improperly or the card is inserted
improperly.
LNK/ACT
1/2/3/4
Green
Ethernet interface working LED

Green: the Ethernet interface is connected properly.

Blinking green: the Ethernet interface is transmitting data.

Off: the Ethernet interface is disconnected or connected
improperly.
2.4.5 Technical specifications
Table 2-15 lists technical specifications of the GE4B sub-card.
Table 2-15 Technical specifications of the GE4B sub-card
Item
Description
Dimensions
129.4 mm (Width) × 243.4 mm (Depth) × 19.8 mm (Height)
Weight
0.23 kg
Power consumption
≤ 4 W
2.5 AC power module (RPA1101-SI-220S12)
2.5.1 Introduction
The RPA1101-SI-220S12 (hereinafter referred to as RPA1101) module is the AC power
module of the ISCOM5508. It supports the following features:

Wide voltage input: 100–240 VAC

Rated output voltage: 12 V; rated output current: 8.3 A

Output overvoltage and overcurrent protection

Input surge current and voltage suppression

Power status LED

Operating temperature: -10 to +70°C
