1. Initial CONNECT Setup
To activate the WES
3
CONNECT, hold down ‘A’ and press ‘B’ three
timesinquicksuccession.AllthreeLEDswillbrieyilluminateandthen
theamberLEDwillash.
Initial setup of the CONNECT is through a series of on-screen options
such as Language, Inspection Delay and Pre-Alarm mode options.
Language Selection
Select language, available options are English, German, French,
Spanish, Italian and Swedish. Select using the arrows to the side of
thescreen-theselectedlanguagewillbehighlighted.Conrmusing
the ‘tick’ button. Language settings can be changed at any time via the
menus within the CONNECT unit.
Inspection Delay
The Inspection Delay setting allows an optional delay period between
triggering a call point and the site wide alarm being raised. This can
allow time for the incident to be validated on site, and a decision to be
made to either
 i)conrmalarmisgenuine,raisesitewidealarmand 
evacuate site, or
 ii)conrmfalseactivation,cancelthealarmandreturnto
normal (non-alarm) state.
Default setting is 0 minutes (ie no delay), but can be set in 1 minute
incrementsuptoamaximum10minutes.Aconrmationscreenwill
be displayed to validate the setting and prevent accidental activation.
Select using the arrows to the side of the screen.
Analscreenwillthenappearconrmingyourselection,thenusethe
‘tick’buttontoconrm.
Note that Inspection Delay can only be set during the initial
network setup process. Once set, the Inspection Delay can only
be set or changed by turning off all networked units, which resets the
network. This will clear any existing unit numbering and other network
settings from the network.
