The Interface has two auxiliary relay outputs and one auxiliary input.
These allow the WES
3
system to be expanded to interact with external
devices.
Pictured right is the layout of the connections inside the Interface Unit
TheInterfaceunitshouldbeinstalledbyasuitablyqualiedperson.
DO NOT connect the Interface to mains current.
Interface
Theinputisunmonitored.Theconnectionofautomaticormanualredetectiondevicesandactivereprotectionsystemssuchassprinklers,gas
suppression systems etc may require additional measures. Cable disconnection or damage could result in the alarm not activating when required
without any fault or warning indication.
All cable lengths must be less than 3 metres long.
Output
The outputs are rated for 24V at up to 2 Amps maximum.
Input
Theinputrequiresa“voltfree”contactfromarelayandshouldnotbeconnectedtopower.
Theinputisunmonitoredandconnectionofautomaticormanualredetectiondevicesmayrequireadditionalmeasures.Cabledisconnectionor
damage could result in the alarm not activating when required without any fault or warning indication.
When NOT in Alarm
When in Alarm
Normally Open (NO)
Normally Closed (NC)
Normally Open (NO)
Normally Closed (NC)
Common (C)
Common (C)
Alarm NOT Triggered
Alarm Triggered
IN-IN+
IN-
IN+
