R&S FSH series User Manual

11 6
PD 1309.6269.62-02
3.9.1 Saving Measurement Results
 Press the SAVE / RECALL key.
 Press the SAVE softkey.
An input box opens and you will be prompted to
enter a name for the data set to be saved.
The name for the most recently stored data set
is suggested in the ‚Name:‘ entry box, which is
highlighted in red. When you press the ENTER key
or the SAVE softkey a second time, the data set is
saved under the suggested name.
The INTERNAL/SD-CARD softkey defi nes whether
the measuring results are stored in the internal
memory or on an SD memory card.
GalaxyE_v1-10_3.indd 116GalaxyE_v1-10_3.indd 116 08.04.2009 15:21:5308.04.2009 15:21:53

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
