2.2 Putting into Operation
The following section describes how to put the
handheld spectrum analyzer into operation.
Section 3 describes the operation of the spectrum
analyzer using simple measurements as examples.
2.2.1 Unpacking the Instrument
The R&S FSH comes in formfi tting packaging that
consists of upper and lower shells. The two shells
are held together by tape.
The packaging contains all accessories supplied.
 Undo the tape to unpack the analyzer.
 Remove the R&S FSH and the accessories.
 Remove the protective foil from the screen.
Each R&S FSH comes with a unique master
PIN. Keep the master PIN in a secure place
away from the R&S FSH. If someone enters
an incorrect PIN three times in succession,
the R&S FSH cannot be used again until
the master PIN is entered.
GalaxyE_v1-10_3.indd 28GalaxyE_v1-10_3.indd 28 08.04.2009 15:21:3908.04.2009 15:21:39

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
