53
E-02
Change the hours with the rotary knob, the
cursor keys or by numeric input.
Confi rm with ENTER.
After input, the cursor automatically moves to the
minutes display. Input is identical to the procedure
for setting the hour display.
After the minutes have been entered, the R&S FSH
verifi es the validity of the entered time. If the time
is not valid, the R&S FSH sets the next valid time.
2.3 Self Alignment
The self alignment calibrates the instrument
settings for vector network analyzer and overrides
the manufacturers calibration stored in the
instrument.
For the self alignment a short circuit (Short), an
open circuit (Open) and 50 ohm match (Load) is
required. In addition, a through connection must
be established with an appropriate cable.
Press the SETUP key.
Press the INSTRUMENT SETUP softkey.
The R&S FSH opens a list of general settings.
Select the SELF ALIGNMENT menu item below
the heading SELF ALIGNMENT with the rotary
knob or the cursor keys ( or ).
Confi rm with ENTER.
