30
PD 1309.6269.62-02
2.2.2 Setting up the Instrument
The Handheld Spectrum Analyzer R&S FSH
has been designed for operation in labs as well
as for on site use for service and maintenance
applications.
For any application, the R&S FSH can be set up to
optimize ease of operation and the viewing angle
of the display.
When used as a desktop
instrument, the R&S FSH can
either be laid fl at or it can be
propped up using the fold-out
support at the back.
The R&S FSH can be laid fl at
for operation from above.
Because the grip is slightly raised at the back, the
R&S FSH is tilted forward to give the optimum
viewing angle for the display.
For use as a desktop, fold out the support at the
rear so that the instrument can easily be operated
from the front and the display can be read easily
(see fi gure above).
For on-site installation and service measurements,
it is best to hold the instrument with both hands.
All the controls are easy to reach (e.g. with your
thumbs). Use of the R&S HA-Z222 carrying bag is
recommended in order to leave both hands free for
work on the device under test.
GalaxyE_v1-10_3.indd 30GalaxyE_v1-10_3.indd 30 08.04.2009 15:21:4008.04.2009 15:21:40

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the R&S FSH series and is the answer not in the manual?

R&S FSH series Specifications

General IconGeneral
Input Impedance50 Ω
Display640 x 480 pixels
Tracking generatorOptional
InterfacesUSB, LAN
Third Order Intercept (TOI)+15 dBm typical
Input VSWR≤1.5:1 (typical)
Input ConnectorN (f)
Power Supply100 V to 240 V
Frequency range9 kHz to 3.6/8/13.6/20 GHz
Battery lifeApprox. 4 hours (standard battery)
