Remote Control Basics
R&S
®
NRPxxS(N)
172User Manual 1177.5079.02 ─ 10
Bit No. Meaning
11 Lower limit fail status register
This bit is set if a displayed value has dropped below a lower limit value.
See Chapter 11.3.8.5, "Operation Lower Limit Fail Status Register", on page 174.
12 Upper limit fail status register
This bit is set if a displayed value has exceeded an upper limit value.
See Chapter 11.3.8.6, "Operation Upper Limit Fail Status Register", on page 174.
13 to 14 Not used
15 Bit 15 is never used.
11.3.8.1 Operation Calibrating Status Register
The CONDition register contains information about whether a sensor is calibrated
and, depending on the configuration of the transition register. The EVENt register indi-
cates whether a calibration was started or completed since the last readout of this reg-
ister.
Querying the register:
●
STATus:OPERation:CALibrating:CONDition?
●
STATus:OPERation:CALibrating[:SUMMary][:EVENt]?
Table 11-11: Meaning of bits used in the operation calibrating status register
Bit No. Meaning
0 Not used
1 Sensor calibrating
The sensor is being calibrated
5 to 15 Not used
11.3.8.2 Operation Measuring Status Register
The CONDition register contains information about whether a measurement is being
performed by a sensor and, depending on the configuration of the transition register.
The EVENt register indicates whether a measurement was started or completed since
the last readout of this register.
Querying the register:
●
STATus:OPERation:MEASuring:CONDition?
●
STATus:OPERation:MEASuring[:SUMMary][:EVENt]?
Status Reporting System
