5 | Setup
34 / 100 80.06.083_iCombiPro-iCombiClassic_IM_en-US
Minimum distance from ceiling
x [mm] 250
x [inch] 10
Gas units
Install the gas unit with a minimum distance between the flue gas pipes of the
unit and the grease filters of the extractor hood/ventilation ceiling.
Minimum distance from ceiling
x [mm] 400
x [inch] 16
Condensation breaker
If the steam from the ventilation pipe cannot be fed directly into an extraction
hood or ventilation ceiling, there must be a minimum distance between the
unit and the ceiling.
