Rational CombiMaster Plus Original Installation Instructions

12 | Initial start-up
80.06.083_iCombiPro-iCombiClassic_IM_en-US 91 / 100
Inserting GN container
1. Slide a flat GN container with the opening facing down into the rack slide
hangers in front of each fan wheel.
>> For unit sizes XS GN to 6 full size GN, there is a GN container in the middle
of the rack rails in front of the fan wheel.
>> For unit sizes 10 half size GN and 10 full size GN, there are two GN contain-
ers in the rack rails, one in the middle of each fan wheel.
>> For unit sizes 20 half size GN and 20 full size GN, there are three GN con-
tainers in the support rack trolley, one in the middle of each fan wheel.
Start self test
1. Close the cabinet door.
2. Start the self-test.
>> During the self-test, the unit is also checked for leaks. If steam escapes from
the closed cooking cabinet door during the self-test, wait until the self-test
is complete and check the door setting.
>> The display shows when the self-test has been completed.
NOTE
If steam escapes from the door during the self-test, the door setting may not
be correct. In this case, check the door setting and reset the door if
necessary.
12.3 iCareSystem AutoDose
*Only iCombi Pro when ordering the option iCareSystem AutoDose. The option
must be ordered separately and is available for unit size 6 half size - 10 full size.
The option cannot be retrofitted.
Observe the regulations for the drain connection in the chapter Drain connec-
tion (Regulations for the wastewater connection [}74]).

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
