5 | Setup
32 / 100 80.06.083_iCombiPro-iCombiClassic_IM_en-US
5.1.2 Distance from heat sources
NOTE
Minimum distance is not observed
To avoid damage to the unit or malfunctions, the unit should be set up with
the specified minimum distance from heat sources or open flames.
NOTE
High ambient temperature next to the installation area (left side of the
unit)
If the temperatures in the installation area on the left side of the unit exceed
80°C [176°F], the heating system is switched off by an automatic safety
switch-off.
NOTE
High ambient temperatures at the rear of the unit
Do not place deep fryers or other heat sources at the rear of the unit.
Set up the unit with a minimum distance from heat sources on the left and
right.
Minimum distance to heat sources
x [mm] 350
x [inch] 14
