5 | Setup
80.06.083_iCombiPro-iCombiClassic_IM_en-US 35 / 100
This space is needed to install a condensation breaker that can be used to direct
the exhaust air into noncritical areas.
Minimum distance from ceiling
x [mm] 500
x [inch] 20
5.2 Installation of tabletop units
WARNING
Unit could fall from the installation surface
Risk of crushing and injury if the unit is tilted or turned.
n
Do not tilt the unit on the installation surface.
n
When turning the unit, ensure that the weight of the unit is evenly
distributed and that the unit is positioned completely on the installation
surface.
WARNING
Height adjustment via unit feet or leveling frame
Danger of burns during operation when loaded on rack rails over 1600 mm
[63 inch].
n
Attach the enclosed safety sticker to the unit.
n
Inform the end user about the danger of the raised rack rails.
