4 | Transport
22 / 100 80.06.083_iCombiPro-iCombiClassic_IM_en-US
a The packaging material is removed.
a The unit is on the transport pallet.
a The unit feet are positioned in the foam rubber frame of the transport pal-
let.
1. Transport the unit to the installation site with the transport pallet. During
transport, look out for protruding components on the underside of the
unit.
>> The unit is on the designated installation surface and is ready for setup and
installation.
4.3 Transport without transport pallet with lift truck
NOTE
Transport without transport pallet with lift truck
Do not transport the unit with a lift truck without protection. Use a wooden
pallet or a wooden beam as protection, for example.
NOTE
Unit size XS GN: Damage to the unit due to incorrect lifting
During transport, make sure that the air filter box and the USB port remain
intact.
Required door width without transport pallet
Unit size XS 6 half
size
6 full
size
10 half
size
10 full
size
20 half
size
20 full
size
x (mm) 630 845 1045 845 1045 925 1145
x (inch) 24 3/4 33 1/4 41 1/8 33 1/4 41 1/8 36 3/8 45 1/8
4.3.1 Transport tabletop units without pallet with pallet truck
a The packaging material is removed.
a The unit rests on the unit base frame.
a To avoid scratches on the underside of the unit, provide protection against
damage to the unit.
