5 | Setup
40 / 100 80.06.083_iCombiPro-iCombiClassic_IM_en-US
5.3 Installation of floor units
5.3.1 Install and align floor units
Lift the floor unit from the transport pallet and install
CAUTION
Danger of tipping during installation
Risk of crushing if the unit tips over onto a person.
n
Note the center of gravity (mass) of the unit.
n
Ensure that the unit does not tip over when the pallet is set down.
CAUTION
Risk of injury due to the weight of the unit
Personal injury and material damage caused by the unit tipping over
n
At least two people are required to install the unit.
a The installation surface is horizontal, free of grease and clean.
a The transport aid is available.
1. Open the screws connecting the transport pallet to the transport aid. Place
the screwed transport aid to the right of the transport pallet.
