Rational iCombi Classic Troubleshooting

1
Service error: 37
Error tree: Moisture control via P1 incorrect
Service error: 37
Unit type: iCombi
V03 · 04/2021 · RTS/Awei · en-GB
Moisture control via P1 incorrect
Set the unit to cold (40 °C) and the "steam" operating mode.
Determine P1 value in diagnosis
P1 value approx. 0.5 V
P1 sensor fault, replace (3017.1011)
Sensor must be installed horizontally.
Pull the fan wheel and clean the hose connection.
P1 value approx. 1 - 2 V
Check temperature thermocouple humidity B4 when the temperature
in the cooking cabinet is 93 °C.
Carry out manual calibration after installing the fan wheel
Follow the fault tree:
Non-uniform cooking result, moisture problems
Temperature B4 reaches at least 90°C
Pull off the connecting hose to P1. Can you
blow through the hose?
Connection hose to p1 blocked.
P1 value approx. 2.7 - 4.7V
Follow the "Manual humidity calibration" procedure
Check insulation thermocouple B4 behind
the fan motor.
Check error history for errors 55 and 56
Yes
No
No
YesNo
Yes
Yes
No Yes
Yes
Yes

Rational iCombi Classic Specifications

General

Model	iCombi Classic
Material	Stainless steel
Cooking Modes	Convection, Steam
Temperature Range	30°C to 300°C
Capacity	10, 20
Power Supply	400V 3-phase
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Cooking Levels	10, 20, or 40
