Raymarine Dragonfly-5 DVS User Manual

Searchingforwaypointsbysymbol
Waypointscanbesearchedforbywaypointsymbol.
FromtheWaypointslist:
1.SelectSearch.
Thesearchpageisdisplayed.
2.SelectSymbol.
Thewaypointssymbollistisdisplayed.
3.Selectthesymbolthatisassignedtothe
waypoint(s)youwanttosearchfor.
Alistofallwaypointsusingtheselectedsymbol
isdisplayed.
4.SelectEraseWptstoerasethelistofwaypoints
fromyoursystem,or
5.SelectMoveWptstomovethewaypointstoa
neworexistinggroup,or
6.SelectAssignSymboltoassignanewsymbol
toallthewaypointsinthesearchresultslist.
Youcanalsoselectawaypointfromthelisttoview
itsdetails,orifaccessedfromtheChartapplication
setagotoordisplaythewaypointintheChart
application.
Searchingforwaypointsbyarea
Waypointscanbesearchedforbyselectinganarea
intheChartapplication.
FromtheChartapplicationmenu:
1.SelectWaypoints.
Thewaypointslistisdisplayed.
2.SelectSearch.
Thesearchpageisdisplayed.
3.SelectArea.
TheChartapplicationisdisplayedwiththearea
searchmenuopen.
4.Selectthelocationfortherstcornerpointofthe
searcharea.
5.Selectthelocationfortheoppositecornerofthe
searcharea.
Aboxisdrawnonthescreenwhichcoversthe
selectedarea.
Iftheboxisdrawninthewrongplaceyoucan
drawanewareabyselecting2newcornerpoints.
6.SelectSearchfromthemenu.
Alistofallwaypointsintheselectedareais
displayed.
7.SelectEraseWptstoerasethelistofwaypoints
fromyoursystem,or
8.SelectMoveWptstomovethewaypointstoa
neworexistinggroup,or
9.SelectAssignSymboltoassignanewsymbol
toallthewaypointsinthesearchresultslist.
Youcanalsoselectawaypointfromthelisttoview
itsdetails,setagotoordisplaythewaypointinthe
Chartapplication.
Waypointsymbols
ARangeofwaypointsymbolsareavailablethatcan
beusedtorepresentdifferentwaypointtypes.
BlackCross RedCross
BlackCircle RedCircle
BlackSquare RedSquare
BlackTriangle RedTriangle
Chartapplication
79

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
