Raymarine Dragonfly-5 DVS User Manual

MenuitemApplicabledisplaysDescriptionOptions
Maintenance•DV
•DVS
•Pro
•5M
Providesdiagnostic
information.Alsoenables
youtoresetthedisplayto
factorysettings.
SeetheMaintenancemenu
sectionfordetails.
BearingMode•Pro
•5M
Determineshowbearingdata
isdisplayed.
•True
•Magnetic(default)
Accessingthesystemsettingsmenu
Dependingondisplayvariant,theSystemSettings
menucanbeaccessedby:
•selectingSystemSettingsfromtheTools&
Settingspage(DVSandPro),orby
•selecting:Menu>SystemSettingsfromthe
applicationmenu(DVand5M).
DVSystemsettingsmenuoptions
TheSystemSettingsmenuontheDVvariant
displayislocatedinthemainapplicationmenu.
Referto11.1SystemSettingsmenufordetailson
availableoptionsforyourdisplayvariant.
5MSystemsettingsmenu
TheSystemSettingsmenuonthe5Mvariant
displayislocatedinthemainapplicationmenu.
Referto11.1SystemSettingsmenufordetailson
availableoptionsforyourdisplayvariant.
SystemLanguages
Thesystemcanoperateinthefollowinglanguages:
English(US)English(UK)
Arabic
Bulgarian
ChineseCroatian
Czech
DanishDutch
FinnishFrench
German
Greek
IcelandicItalian
JapaneseKoreanNorwegian
PolishPortuguese
(Brazilian)
Russian
SlovenianSpanishSwedish
Turkish
Selectingalanguage
FromtheTools&Settingsmenu:
1.SelectSystemSettings.
2.SelectLanguage:
3.Selecttherelevantlanguagefromthelist.
Tools&Settings
97

Raymarine Dragonfly-5 DVS Specifications

General

Display Size	5 inches
GPS	Yes
Chartplotter	Yes
Waterproof Rating	IPX6 and IPX7
Transducer	Included
Depth Range	Up to 600 feet (183 meters)
Mounting	Flush mount or bracket mount
Display Resolution	800 x 480 pixels
Dimensions	145 mm x 145 mm x 56 mm
Weight	0.7 kg
