Plus Series Fishfinders
Creating a New
Route
You can edit a route after you have finished making it, as described in Editing
a Route on page 5-28.
➤ To make a new route by placing waypoints:
Note: You can pan the chart and change the scale while placing waypoints.
1. If necessary, move the cursor to the area in which you wish to make the
route, and select a suitable chart scale.
2. Press the ROUTE soft key, then press the MAKE ROUTE soft key. The make
route soft keys are displayed:
3. Move the cursor to the position on the chart where you want your first way-
point to be. Press the PLACE WAYPOINT soft key.
Note: You can position the cursor on an existing waypoint – the text
WPT
indi-
cates you are re-using the waypoint rather than placing a new one. This way-
point is included in the route when you press
PLACE WAYPOINT
.
The waypoint appears on the screen at the cursor position. The number
displayed alongside the waypoint identifies its position in the route. The
new waypoint is temporarily added to the waypoint list with the first avail-
able waypoint number. The waypoints in the current route are re-num-
bered to identify the new positions.
Note: If you Clear the route before it is Saved, the waypoint is removed.
4. Move the cursor to the next waypoint position. A dotted line connects the
cursor to the last placed waypoint.
5. Press PLACE WAYPOINT again. The waypoint is placed and the dotted line
changes to a solid line.
If you placed the waypoint incorrectly, you can delete the last-placed way-
point by pressing the UNDO WAYPOINT soft key.
6. Repeat steps 4 and 5 until you have placed all your waypoints. You can
have up to 50 waypoints in a route.
7. When you have entered all your waypoints, either:
Press the ACCEPT ROUTE soft key (or ENTER) to complete the route. Your
route is displayed on the screen, and is the current route, but it is not active.
The first waypoint of a new route is outlined with a square, indicating that
it will be the target waypoint when the route is activated. If selected, the
waypoint data box is displayed for the target waypoint.
ROUTE
MAKE
ROUTE
D5575-1
PLACE
WAYPOINT
UNDO
WAYPOINT
ACCEPT
ROUTE
USE
WPT LIST
PLACE
WAYPOINT
PLACE
WAYPOINT
UNDO
WAYPOINT
ACCEPT
ROUTE
