Chapter 5: Standard Chart Operations 5-21
Creating a New
Route
➤ To make a new route using the Waypoint List:
1. Press the ROUTE soft key; the route soft keys are displayed.
2. Press the MAKE ROUTE soft key; the make route soft keys are displayed
3. Press the USE WPT LIST soft key; the MAKE ROUTE screen is displayed with
its associated soft keys.
The available Waypoints are listed in the left hand column (alphanumeric); the
right hand column lists the waypoints in the New Route, the number indicates
its order in the route. The lower part of the table shows position, bearing and
range of the highlighted waypoint.
You use the trackpad left/right to move control between the two columns (the
highlighted title indicates the selected column) and the trackpad up/down to
scroll through the lists.
4. Select a waypoint from the Waypoint List then go to the New Route col-
umn and select a position in the list.
Note: A waypoint cannot be used more than once in a route; those already
used are displayed in a lighter shade of gray.
5. Press the INSERT WAYPOINT soft key to place the waypoint below the
selected position in the Route. You can have up to 50 waypoints in a route.
ROUTE
D4167-1A
MAKE
ROUTE
EDIT
ROUTE
CLEAR
ROUTE
MORE!
MAKE
ROUTE
D5575-1
PLACE
WAYPOINT
UNDO
WAYPOINT
ACCEPT
ROUTE
USE
WPT LIST
USE
WPT LIST
D5574-1
INSERT
WAYPOINT
REMOVE
WAYPOINT
ACCEPT
ROUTE
USE
CURSOR
WAYPOINTS
MAKE ROUTE
50°50^000N
001°06^000W
COWES
GURNARD LEDGE
MAIN CHANNEL
NEEDLES FAIRWAY
PORT SOLENT
348°m 2.30nm
50°52^230N
001°02^390W
300°m 1.00nm
01 HARBOUR
02 MAIN CHANNEL
03 COWES
04 LYMINGTON
NEW ROUTE
INSERT
WAYPOINT
