Chapter 3: Getting Started & Adjusting the Display 3-3
Switching the
Display On and Off
• Range adjustment can be made on either master or repeater display, but any
changes made are used on both displays.
• Simulator mode is repeated from the master, but cannot be selected on the
repeater display.
Figure 3-2: Typical Fishfinder Display at Switch On
➤ To set the fishfinder display as a master or repeater:
1. Press the MENU key, then press the SONAR SET UP soft key. The sonar set
up pop-up window is displayed.
2. Use the trackpad to move the selection bar over the option SONAR HSB
MODE. The HSB mode soft keys are displayed.
3. Press the appropriate soft key to set the display as a MASTER or REPEATER.
Press ENTER twice to return to the default display.
D5008-2
50
75
ZOOMFREQUENCY
BTM.LOCK A-SCOPE
AUTO G RZ
ft
45
52
38
8
50kHz
0
100
25
