Chapter 4: Setting Up 31
Chapter 4: Setting Up
4.1 Introduction
When you have installed your system and are familiar with its basic
operation, you can set it up to operate according to your preferences.
This is achieved using the function controls that are displayed when the
PAGE key is pressed. These settings can be changed at any time.
When your preferences are set, they remain until they are reset and are
retained even when the unit is powered off.
This chapter covers the following topics:
• System parameters and default settings
• Chartplotter-specific parameters and default settings
• GPS status and default settings
The set up parameters are selected via three soft keys:
• System Set Up: controlling overall functionality
• Chart Set Up: controlling the chartplotter functions, including way-
point information and vectors
• GPS Set Up: displaying the GPS Antenna status
Note: The additional TRACK SET UP function is covered in Chapter 5:Op-
eration.
This section provides instructions for displaying and changing the
factory default values to your preferences. The following sections list the
parameters with their possible settings and describe the function of each
parameter in turn.
4.2 System Set Up Parameters
➤ To set the System default parameters:
1. From chart mode, with no function bar displayed, press the PAGE key
to display the SET UP function bar:
D4694_1
