8. To set the focal distance for each point, do any of the following:
If the focal distance is N/A, select a rack point. The camera uses an autofocus algorithm to calculate the focal
distance.
Select a rack point, manually change the focal distance, and select Set.
Select a rack point, and select Refocus. The camera uses an autofocus algorithm to re-calculate the focal
distance.
Figure: Set Up Rack Points
9. To set a rack point location, follow the instructions below:
A.
Select the rack point: A, B, C, or D.
B.
Select Close to return to the main screen.
C. Tap and hold the touchscreen where you want the rack point to be, or press and drag the rack point. When you
move a rack point, the camera autofocuses.
NOTE: To prevent a rack point from being accidentally moved, the rack point is less sensitive to touch than the
other focus targets. To fine-tune the rack point location, first drag the rack point farther than it needs to be, and
then drag it to where you want it to be.
NOTE: To view the focus distance for each rack point on the main screen, go to Menu > Settings > Display >
Modes and enable Rack Show Distance mode. For more information, go to "Lens" on page127.
