Regency CV40E-12 - Lighting Procedure; Shutdown Procedure

12 | City Series CV40E-12
owner's information
* Not oered on all models.
Prior to operating this appliance, please read the instructions packaged with
the remote control to understand how to operate the system.
1. Ensure the battery holder switch is in the REMOTE position and / or wall-
mounted battery holder (if equipped) is in the REMOTE position.
2. Press and release the ON/OFF button on the remote hand-held transmitter
(see Diagram 1). A beep should be heard from the receiver. If not using
the remote, turn the appliance on by sliding the battery holder switch to
the ON position.
3. After approximately four seconds for non power vent models or 15 seconds
for power vent models, the spark ignition system will spark for 60 seconds
to light the main burner.
Shutdown Procedure
1. Press the ON/OFF button on the remote.
2. Before service is performed, you must disconnect the power and shut o
gas to the appliance.
Diagram 1
4. The unit will turn on.
5. Reset the system as follows:
a) Turn the system o by pressing the ON/OFF button on the remote .
b) Wait 5 minutes, then repeat the process from step 2.
Lighting Procedure
Continuous Pilot/Intermittent Pilot (CPI/IPI) selection
See remote control instructions for details.
*
*
*
NOTE
The rst try for ignition will last approximately 60 seconds. If there
is no ame ignition (rectication), the board will stop sparking for ap-
proximately 35 seconds. After wait time, the board will start second
try for ignition by sparking for approximately 60 seconds. If there is
still no positive ignition, the board will go into lock out.
Back lit LCD display
On/o key
Thermostat key
Up/down arrow key
Mode key
IMPORTANT
The remote control system supplied has several options
for starting/operating the appliance using the battery
holder and ON/OFF key on the hand-held transmitter.
NOTE
Power vent models do not have a continuous pilot option.
