City Series CV40E-12 | 65
installation
Clean Trim Faceplate Installation
920-259
04.17.20
1
CITY SERIES
1. Frame in fireplace and install finishing material. (Clean Trim Faceplate can
accommodate finishing materials for 1/2 inch to 1 1/8".)
2. Prior to installing outer liner panels and barrier glass remove finishing trim
plates from right and left sides.
4. Hand bend attachment tabs so they bend past the magnets to the metal
wall inside the opening.
3. Insert Clean Trim Faceplate into fireplace opening.
5. Affix Clean Trim Faceplate with self-tapping screws that are included in
the box.
CLEAN TRIM FACEPLATE INSTALLATION
