64 | City Series CV40E-12
installation - general
Proame Wall Mount Transmitter
WALL MOUNTING
The Proame remote control/transmitter is supplied with an adapter for wall
mounting.Install the controller 59" (1.5m) above the oor level, well away
from heat sources, kitchens, doors or windows.
Metalllic structures or radio interferences can reduce the operative distance
of the device.
Make sure to attach the adapter in a level plane without any distortion.
Proceed as follows:
- Detach the adapter from the body of the remote control (see Fig. A).
- Position the adapter on the wall, mark the points for the xing holes
and drill the wall.
- Fix the adapter on the wall using the mounting hardware supplied
with the remote control.
- Insert the remote control onto the adapter as shown in Fig. B.
Fig. A: Detach the adapter from the
body
Fig. B: Adapter and remote control
