ADT and ADT View user guide
ADTi-100
6 Using the ADT View software with ADTi-100
1 2
3
5
6
7
8
9
10
11 12 13
1 ADTi serial number
2 Connect to another ADT. Opens ADT
selection screen in a new tab (section 3.2.1)
3 Linear/rotary scale selection
(sections 6.5.1 and 6.5.2)
4 Readhead serial number
5 Signal screen (section 6.1)
6 Lissajous (X-Y) screen (section 6.2)
7 Signal strength vs position screen
(section 6.3)
8 Velocity screen (section 6.4)
9 Position display (Digital readout) screen
(section 6.5)
10 Configuration screen (section 6.6)
11 Automatic Gain Control (AGC) switching
(section 6.1.5)
12 Limit indication where applicable
13 Alarm and warning log (section 6.1.6)
4
