ADT and ADT View user guide
ADTi-100
6.3 Signal strength versus position screen
Thesignalstrengthvspositionscreenplotsthesignalsizealongtheaxislength.
1 Save data
2 PlotofthesignalsizeandIREDdrivealongtheaxis
(section 6.3.1)
NOTE:Theplotcanbezoomedandpanned.See
section 6.3.2.3 for more information
3 Enable/disable gridlines
4 Select to show/hide Graph Controls
5 Start/Stop a plot (alternatively press the space bar)
(section 6.3.2.2)
6 Resetplotmagnication
7 Trigger mode selection (section 6.3.2.1)
8 Reference mark (Z) and limit (P & Q) positions
alongtheaxiswhereapplicable
When an alarm or warning occurs, a pop-up describing
the error condition will be displayed for 3 seconds.
See section 6.1.6 for more information on alarms and
warnings.
1 2
8
4
5
6
7
3
