Chapter 5
5-6 BiPAP® Focus™ Ventilator Service Manual © Respironics, Inc. REF 1029568 Rev A
Diagnostic Mode and Troubleshooting
Figure 5-6: Entering a Name for the Connection to the BiPAP Focus Ventilator
5. Select the appropriate serial port (Figure 5-7 shows Com1 selected),
then click OK.
Figure 5-7: Selecting the Serial Port
6. Enter these settings for the serial port (Figure 5-8):
Figure 5-8: Serial Port Settings
