Revolectrix Dual PowerLab 8x2 User Manual

26
Charge/discharge/cycle packs in parallel
Dual PowerLab 8x2 can charge, discharge or cycle up to 16 LiPo or A123 packs in
parallel. Parallel operations can save a lot of time, but you must follow these rules:
 Always use Safe Parallel Adapters or the MPA (available at the REVOLECTRIX Web
sites). Never use standard adapters.
 Connect only one pack per Safe Parallel Adapter. Daisy-chain multiple adapters!
 Parallel operations using Safe Parallel Adapters requires that you connect both the
balance wires and discharge wires to the Dual PowerLab 8x2.
 Always observe proper polarity! 
 Packs must have the same cell count.
 Packs must be the same chemistry.
If not using the MPA, the best way to connect discharge wires in parallel is to stack the
plugs on the safety banana cables like this:
Charging proceeds like single-pack charging, except at the Parallel Packs? question,
use INC and DEC to specify the number of packs connected in parallel. Dual PowerLab
8x2 multiplies the preset’s charge/discharge rates by the number of “P” selected.
See also
Connect packs: Configuration B
