ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 146
Tx Status Bits
0x01 Tx power level fail.
0x02 Internal Use only.
0x04 VSWR fail.
0x08 VCO lock fail.
0x10 Tx signal present.
0x20 Tx signal still ON/OFF.
0x40 Internal use.
0x80 Rx signal present.
CamStatus
Alarm Module Status Bits
0x0000 Alarm not active.
0x0001 Alarm active.
Note: Each trap refers to only one alarm input, as detailed by the axmAlarmSourceNumber and
axmAlarmItemNumber objects
AccessEvent
Access Event Bits
0x0000 (Always)
Note: This trap is only sent when the number of sequential log attempts is ≥ 3.
IsolationTestStatus
Isolation Test Status Bits
0x0001 Not used.
0x0002 Rx Gain or Tx Rejection fail.
0x0004 RxA level out of range.
0x0008 VCO lock fail (Rx Gain only).
0x0010 RxB level out of range.
0x0020 Not used.
0x0040 RxE level out of range.
0x0080 Not used.
0x0100 Not used.
0x0200 Not used.
0x0400 RxA enabled.
0x0800 RxB enabled.
0x1000 RxE enabled.
0x2000 RSM Present.
Note: The axmAlarmSourceNumber is one of 21, 22 or 23 (as detailed in the Syntax Integer declaration for
the axmAlarmSourceNumber object).
