ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 147
axmAlarmDescription
OID 1.3.6.1.4.1.32327.2.2.2.1.2.5
Syntax Text String
Description This is a brief textual description of the alarm status. The included detail depends on the alarm type.
The following are examples:
Restart: System Restart
SystemStatus: SYS=FAIL, RX=OK, TXPWR=OK, TXVSWR=FAIL
If a CAM or SAM is present an “ALMMOD=” status is added.
If a Receive Systems Module is present a “RSM=” status is also added.
ChannelStatus: For a Rx channel: – PWR=OK(-97.5), VCO=OK, RX=ON
For a Rx Channel with Receive Systems Module:
- PWR=OK(A=-97.5,B=-95.3,E=-101.2), VCO=OK, RX=ON
For a Tx channel: - PWR=OK(39.5), Internal Use only, VSWR=OK(1.52),VCO=OK, TX=ON
CamStatus: SAM Input, DI1-6 - Test IP-6, STATUS=FAIL
AccessEvent: System Access Lockout Alert, Source=10.3.5.119, Count=3
IsolTestStatus: For Antenna Isolation:
– Ant Isolation,STATUS=OK(A=82.0,B=83.1,E=78.7 dB,900.000000 MHz)
For Rx System:
- Rx System,STATUS=OK(A=-0.1,B=-0.4,E=-1.3 dB,870.000000 MHz)
For Tx Rejection:
- Tx Rejection,STATUS=OK(A=95.1,B=97.8,E=91.4 dB,915.000000 MHz)
Note that ‘A’, ‘B’ and ‘E’ values are only included if a Receive Systems Module is in
use.
axmAlarmState
OID 1.3.6.1.4.1.32327.2.2.2.1.2.6
Syntax Integer
Description The alarm status for this trap. A value of 1 represents OK, a value of 2 is FAIL.
axmAlarmDateTime
OID 1.3.6.1.4.1.32327.2.2.2.1.2.7
Syntax Date and Time
Description The time stamp for when this trap was sent.
axmAlarmSourceNumber
OID 1.3.6.1.4.1.32327.2.2.2.1.2.8
Syntax Integer
Description This identifies the source of the alarm event. This object, although included with every trap,
is only relevant for the following alarm types:
ChannelStatus:
0 – RxPort 1 – TxPort-1 2 – TxPort-2 3 – TxPort-3 4 – TxPort-4
CamStatus:
Possible values are::
11 – Alarm Module 1 12 – Alarm Module 2 13 – Alarm Module 3 14 – Alarm Module 4
15 – Alarm Module 5 16 – Alarm Module 6 17 – Alarm Module 7 18 – Alarm Module 8
19 – Alarm Module 9 20 – Alarm Module 10
IsolTestStatus:
21 – Antenna Isolation 22 – Rx System 23 – Tx Rejection
