Bit Switches - 2
SM 93 D418
Fax Option
Type 9001
D418
Relationship between available paper sizes and printer width used in the setup
protocol
Available Paper Size Printer width used in the Protocol (NSF/DIS)
A4 or 8.5" x 11" 297 mm width
B5 256 mm width
A5 or 8.5" x 5.5" 216 mm width
No paper available (Paper end) 216 mm width
Printer Switch 02 (SP No. 1-103-003)
No Function Comments
0
1st paper feed station usage for
fax printing
0: Enabled
1: Disabled
1
2nd paper feed station usage
for fax printing
0: Enabled
1: Disabled
2
3rd paper feed station usage for
fax printing
0: Enabled
1: Disabled
3
4th paper feed station usage for
fax printing
0: Enabled
1: Disabled
4
LCT usage for fax printing
0: Enabled
1: Disabled
0: The paper feed station can be used to print
fax messages and reports.
1: The specified paper feed station will not be
used for printing fax messages and reports.
Do not disable usage for a paper feed
station which has been specified by
User Parameter Switch 0F (15), or
which is used for the Specified
Cassette Selection feature.
