Output Jogger Unit (B703)
D062/D063/D065/D066 2-80 SM
2.13 OUTPUT JOGGER UNIT (B703)
2.13.1 ACCESSORIES
Check the accessories and their quantities against the following list.
Description Q’ty
1. Jogger Unit 1
2. Tapping Screws - M3 x 6 2
2.13.2 INSTALLATION PROCEDURE
The Output Jogger Unit B703 can be installed only on the 2000/3000-Sheet
Finisher D373/D374.
Always switch the machine off and unplug the machine before doing any of the
following procedures.
1. Turn the main machine switch off.
2. Disconnect the finisher from the main frame.
To Next Page
