Ricoh Aficio MP 8001 Service Manual

DIP Switch Tables
D062/D063/D065/D066 5-34 SM
5.8 DIP SWITCH TABLES
5.8.1 BCU (BASE ENGINE CONTROL UNIT)
BCU Base Board DIP SW101
No. Function Default Comments
1 DFU -
2 DFU OFF
3 DFU OFF
4 DFU OFF
5 DFU OFF
6 Region Selection - Japan: 6, 7, 8/ OFF, OFF, OFF
7 Region Selection - NA (115V): 6, 7, 8/ ON, OFF, OFF
8 Region Selection - EU (220/240V): 6, 7, 8/ OFF, ON, OFF
DFU: Design, Factory Use only. Do not change these settings.
